Milesight UC100 LoRaWAN Controller
£45.00
Tags:
Milesight IoT/LoRaWAN Controller UC100 is an easy and intelligent device dedicated to collecting data from on-site Modbus RTU devices, and transmitting them to the Internet via LoRaWAN®.
- Modbus RS485 to LoRaWAN® Converter
- Data Collection Up to 16 Registers
- Local & Remote Easy Configuration
- Milesight D2D Controller & Agent
Choose Quantity
Product Details
Specifications
RS485 Interface
Offering a RS485 interface for connecting a range of field sensors or devices.
LoRaWAN® Based
Milesight D2D
- 3.5 mm Terminal Block
- Reading Up to 16 Registers
- RS485 to LoRaWAN Controller UC100 is compatible with LoRaWAN® gateways
- With a range of up to 15 km in rural areas and 2 km in urban areas
- CN470/RU864/IN865/EU868/US915/AU915/KR920/AS923
Milesight D2D protocol featuring LoRa enables the UC100 to communicate with other Milesight LoRaWAN® node devices within 1 second without a LoRaWAN® gateway.
Easy Local & Remote Configuration
Intelligent Trigger System Users are able to set up 16 commands based on custom trigger conditions (If-Then Statements) & actions to realize intelligent task.
- When Working as a Milesight D2D Controller Device. (Triggered by RS485 device to send command to control other Milesight D2D agents)
- When Working as a Milesight D2D Agent Device. (Receiving command from other Milesight D2D controllers to control local RS485 device)
- USB Type-C Port – Local Configuring
- LoRa Downlink – Remote Configuring
Autonomous Operation Milesight RS485 to LoRaWAN Controller UC100 can execute the commands autonomously even when the network is unavailable.
Milesight IoT Cloud
Flexible Installation
- Store, manage and analyze all your data with a few clicks
- Android & iOS versions allow you to manage devices at your fingertips
Specification
- TechnologyLoRaWAN®, Milesight D2D
- Interface Type3.5 mm Terminal Block
- Configuration Port1 × Type-C
- LED Indicator1 × System, 1 × ACT
- ModeOTAA/ABP Class C
- Sensitivity-137dBm @300bps
- Port1 × RS485
- IP RatingIP30
